V800 Series High Performance Closed-Loop Vector Inverter User Manual
● Insulation resistance: iron core-winding 1000VDC, insulation resistance ≥100MΩ；
● Reactor noise is less than 70dB (test at the point of 1m horizontal distance with reactor)；
● Temperature rise is less than 70K.
2, Parameter Configuration of AC Input Reactor
Inverter Power
(KW)
Reactor Model
Size
L*W*H (mm)
Mounting
Dimension
(mm)
Installation
Terminal Aperture
(mm)
0.7
AKSG10A/5V
140*85*140
75*55
Φ6
1.1
AKSG10A/5V
140*85*140
75*55
Φ6
1.5
AKSG10A/5V
140*85*140
75*55
Φ6
2.2
AKSG10A/5V
140*85*140
75*55
Φ6
3.0
AKSG10A/5V
140*85*140
75*55
Φ6
4.0
AKSG15A/5V
140*85*140
75*55
Φ6
5.5
AKSG15A/5V
140*85*140
75*55
Φ6
7.5
AKSG20A/5V
175*130*140
82*75
Φ6
9.0
AKSG30A/5V
175*130*140
82*75
Φ6
11
AKSG30A/5V
175*130*140
82*75
Φ6
15
AKSG40A/5V
210*120*190
110*70
Φ8
18.5
AKSG50A/5V
210*120*190
110*70
Φ8
22
AKSG60A/5V
210*165*170
110*85
Φ8
30
AKSG80A/5V
210*165*170
110*85
Φ8
37
AKSG110A/5V
210*165*170
110*85
Φ8
45
AKSG125A/5V
210*165*170
110*85
Φ8
55
AKSG150A/5V
270*170*220
155*85
Φ10
12.4.4 AC OUTPUT REACTOR
AC output reactor is mounted at output terminal of inverter to restrain capacitive
charging current of connecting cable between inverter and motor, voltage built-up rate of
PWM wave of passivated inverter, improve power factor and quality of power grid as well
as stabilize waveform.
1. Performance index of AC output reactor
● Rated operational voltage: 380V/50Hz；
