6.2.10 STEADY RUNNING
Function
Code
Name
Setting Range and Description
Minimu
m Unit
Factory
Default
Change
Limit
F1.4.39
Acceleration/deceleration
current limiting level
120~180(%)
1
160
F1.4.40
Strong start current limiting level
120~200(%)
1
160
F1.4.41
Strong start current holding time
0.0~5.00Sec.
0.01
0.0
F1.4.42
Function selection for adjustors
_ _ _ X: Overvoltage
suppression adjustor
0: Closed
1: Effective (Frequency increasing
suppression)
2：Terminal inputs
_ _ X _: Under voltage
suppression adjustor
0: Closed 1: Effective
_ X _ _: Frequency modulation
and current limiting adjustor
0: Closed 1: Effective
X _ _ _ : Failure Auto Recovery
Mode
0：Speed tracking start
1：Normal Start
1
0111
F1.4.43
Action level of the overvoltage
adjustor
660~800V
1
740
F1.4.44
Overvoltage adjusting gain
0.10~10.00
0.01
1.00
F1.4.45
Action level of the under voltage
adjustor
[FF.2.35]~480V
1
400V
F1.4.46
Under voltage adjusting gain
0.10~10.00
0.01
1.00
F1.4.47
Action level of the frequency
decreasing and current limiting
adjustor
20~200(%)
1
190
F1.4.48
Adjusting gain of the frequency
decreasing and current limiting
adjustor
0.10~10.00
0.01
1.00
F1.4.49
Recovery times of fault self
resetting
0~5 (the self-recovery function is
deactivated when it is set to 0)
1
0
F1.4.50
The recovery waiting time of
fault self resetting
0.2~100.0Sec.
0.1
1.0
F1.4.51
Time period for self resetting
timing
900~36000Sec.
1
3600
F1.4.52
Selection of self resetting fault
_ _ _ X: Over current
0: Self resetting forbidden
1: Self resetting permitted
_ _ _ X: Overvoltage
0: Self resetting forbidden
1: Self resetting permitted
_ _ _ X: Output grounding
0: Self resetting forbidden
1: Self resetting permitted
X _ _ _: Running under voltage
0: Self resetting forbidden
1: Self resetting permitted
1
0000
F1.4.53
Display coefficient
0.001~60.000
0.001
1.000
