6.2.25 BUILT-IN AUXILIARY COUNTER
Function
Code
Name
Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
F5.2.20
Counter 1 operating
mode (H)
_ _ _ X: Counter pulse selection (Function
No. 44, 45)
0: Multifunctional terminal "Voideffective"
1: Multifunctional terminal "effectivevoid"
2: Aforesaid two conditions are both effective
_ _ X _: Starting mode
0: Start immediately after power-on (no
trigger start)
1: Multifunctional terminal trigger (Function
No. 46-47)
2: StopRun status change triggering (edge
triggering)
3: RunStop Status change triggering (edge
triggering)
_ X _ _: Counter resetting source
0: Multifunctional terminal
(Function No.48~49)
1: Set value 1 reaches auto resetting
2: Set value 2 reaches auto resetting
X _ _ _：Counter save data when power off
0：Counter not save data when power off
1：Counter save data when power off
1
0000
F5.2.21
Counter 2 operating
mode (differed from
timer: in case of no
resetting, continue
counting until
overflow, and then
continue to count from
0) (H)
1
0000
F5.2.22
Set value 1 of counter
1
0~65535
1
1000
F5.2.23
Set value 2 of counter
1
0~65535
1
2000
F5.2.24
Set value 1 of counter
2
0~65535
1
1000
F5.2.25
Set value 2 of counter
2
0~65535
1
2000
F5.2.26
Counter 1 output
signal(H)
_ _ _ X: Output signal1
0: Reach set value 1 (0.5 Sec.pulse)
1: Reach set value 2 (level)
2: Set value 1 reached and reversed
3: Reach set value 2 (0.5 Sec.pulse)
4: Reach set value 5 (level)
5: Set value 1reached and reversed
6: Set value 1 or set value 2 reached and
reversed
_ _ X _: Output signal 2
The same as above
_ X _ _: Reserved
X _ _ _: Reserved
1
0000
F5.2.27
Counter 2 output
signal(H)
1
0000
