6.2.18 ANALOG INPUT
Function
Code
Name
Setting Range and
Description
Minimum
Unit
Factory
Default
Change
Limit
F4.0.00
AI1 min. value (0~10V)
0.00~[F4.0.01]
0.01
0.0
F4.0.01
AI1 max. value (0~10V)
[F4.0.00]~10.00V
0.01
10.00
F4.0.02
AI2 min. value (4~20mA)
0.00~[F4.0.03]
0.01
4.00
F4.0.03
AI2 max. value (4~20mA)
[F4.0.02]~20.00mA
0.01
20.00
F4.0.04
AI3 min. value (-10V~10V)/
standard expansion card
-10.00~[F4.0.05]
0.01
0.00
F4.0.05
AI3 max. value (-10V~10V)/
standard expansion card
[F4.0.04]~10.00V
0.01
10.00
F4.0.06
AI1 filtering time coefficient
1~1000ms
1
10ms
F4.0.07
AI2 filtering time coefficient
1~1000ms
1
10ms
F4.0.08
AI3 filtering time coefficient/
standard expansion card
1~1000ms
1
10ms
6.2.19 ANALOG INPUT CURVE CORRECTION
Function
Code
Name
Setting Range and
Description
Minimum
Unit
Factory
Default
Change
Limit
F4.1.09
AI1 curve correction point 1
[F4.0.00]~[F4.0.01]
0.01
0.0
F4.1.10
AI1 curve correction value1
[F4.0.00]~[F4.0.01]
0.01
0.0
F4.1.11
AI1 curve correction point 2
[F4.0.00]~[F4.0.01]
0.01
10.00
F4.1.12
AI1 curve correction value 2
[F4.0.00]~[F4.0.01]
0.01
10.00
F4.1.13
AI2 curve correction point 1
[F4.0.02]~[F4.0.03]
0.01
4.00
F4.1.14
AI2 curve correction value 1
[F4.0.02]~[F4.0.03]
0.01
4.00
F4.1.15
AI2 curve correction point 2
[F4.0.02]~[F4.0.03]
0.01
20.00
F4.1.16
AI2 curve correction value 2
[F4.0.02]~[F4.0.03]
0.01
20.00
F4.1.17
AI3 zero hysteresis/
standard expansion card
0.0~2.00
0.01
0.10
F4.1.18
AI3 curve correction point 1/
standard expansion card
[F4.0.04]~[F4.0.05]
0.01
0.0
F4.1.19
AI3 curve correction value 1/
standard expansion card
[F4.0.04]~[F4.0.05]
0.01
0.0
F4.1.20
AI3 curve correction point 2/
standard expansion card
[F4.0.04]~[F4.0.05]
0.01
10.00
F4.1.21
AI3 curve correction value 2/
standard expansion card
[F4.0.04]~[F4.0.05]
0.01
10.00
