6.2.27 MOTOR TEMPERATURE DETECTION
Function
Code
Name
Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
F5.4.43
Motor temperature sensor
0: None
1: 1 X PT100
2: 2 X PT100
3: 3 X PT100
4: PTC sensor
5: Thermoswitch (normally closed)
6: Thermoswitch (normally open)
1
0
F5.4.44
Sensor current source
providing terminal (exceeding
parameter)
0: None
1: AO1
2: AO2
F5.4.45
Temperature input channel
0: None
1: AI1 input (PT100 or PTC)
2: AI3 input (PT100 or PTC)
3: DI1~DI9 (thermoswitch)
1
0
F5.4.46
Alarm action threshold value
-10.0~500.0 (0~5000 Ω/PTC)
0.1
110.0
F5.4.47
Protection action threshold
value
-10.0~500.0 (0~5000 Ω/PTC)
0.1
130.0
6.2.28 MULTI-STAGE FREQUENCY SETTING
Function
Code
Name
Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
F6.0.00
1st operating frequency
[F0.1.22]~[F0.1.21]
0.01
5.00
F6.0.01
2nd operating frequency
[F0.1.22]~[F0.1.21]
0.01
10.00
F6.0.02
3rd operating frequency
[F0.1.22]~[F0.1.21]
0.01
15.00
F6.0.03
4th operating frequency
[F0.1.22]~[F0.1.21]
0.01
20.00
F6.0.04
5th operating frequency
[F0.1.22]~[F0.1.21]
0.01
25.00
F6.0.05
6th operating frequency
[F0.1.22]~[F0.1.21]
0.01
30.00
F6.0.06
7th operating frequency
[F0.1.22]~[F0.1.21]
0.01
35.00
F6.0.07
8th operating frequency
[F0.1.22]~[F0.1.21]
0.01
40.00
F6.0.08
9th operating frequency
[F0.1.22]~[F0.1.21]
0.01
45.00
F6.0.09
10th operating frequency
[F0.1.22]~[F0.1.21]
0.01
50.00
F6.0.10
11th operating frequency
[F0.1.22]~[F0.1.21]
0.01
25.00
F6.0.11
12th operating frequency
[F0.1.22]~[F0.1.21]
0.01
5.00
F6.0.12
13th operating frequency
[F0.1.22]~[F0.1.21]
0.01
15.00
F6.0.13
14th operating frequency
[F0.1.22]~[F0.1.21]
0.01
35.00
F6.0.14
15th operating frequency
[F0.1.22]~[F0.1.21]
0.01
50.00
