Functional Parameter Table
V800 Series High Performance Closed-Loop Vector Inverter User Manual
82
Function
Code
Name
Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
Fb.2.37
reverse
Fb.2.38
Spindle orientation angle 1
0~359.9
0.1
45.0
Fb.2.39
Spindle orientation angle 2
0~359.9
0.1
90.0
Fb.2.40
Spindle orientation angle 3
0~359.9
0.1
135.0
Fb.2.41
Spindle orientation angle 4
0~359.9
0.1
180.0
Fb.2.42
Spindle orientation angle 5
0~359.9
0.1
225.0
Fb.2.43
Spindle orientation angle 6
0~359.9
0.1
270.0
Fb.2.44
Spindle orientation angle 7
0~359.9
0.1
315.0
Fb.2.45
Spindle stop angle
0~359.9
0.1
0.0
Fb.2.46
Spindle transmission ratio
(detection spindle speed:
Spindle Revolution )
0.010~50.000
0.001
1.000
×
Fb.2.47
Spindle orientation/Position
reach error
0~500
1
5
Fb.2.48
reverse
Fb.2.49
reverse
6.2.46 VIRTUAL INPUT AND OUTPUT
Function
Code
Name
Setting Range and Description
Minimu
m Unit
Factory
Default
Change
Limit
FF.0.00
FF configuration parameter
locking function (H)
_ _ _ X: FF parameter modification
forbidden
0: Modification forbidden
1: Modification permitted
_ _ X _: Reserved
_ X _ _: Reserved
X _ _ _: Initialization of FF
parameter group
0: Forbidden
1: Permitted
1
0000
FF.0.01
Definition of virtual output node
(SDO1)
0~71
1
0
FF.0.02
Definition of virtual output node
(SDO2)
0~71
1
0
FF.0.03
Definition of virtual output node
(SDO3)
0~71
1
0
FF.0.04
Definition of virtual output node
(SDO4)
0~71
1
0
FF.0.05
Definition of virtual output node
(SDO5)
0~71
1
0
FF.0.06
Definition of virtual output node
(SDO6)
0~71
1
0
FF.0.07
Definition of virtual output node
(SDO7)
0~71
1
0
FF.0.08
Definition of virtual output node
0~71
1
0
