V800 Series High Performance Closed-Loop Vector Inverter User Manual
6.2.21 ANALOG INPUT POWER FAILURE DETECTION
Setting Range and Description
Analog input power
failure detection function
_ _ _ X: AI1power failure detection
0: Void 1: Effective
_ _ X _: AI2 power failure detection
0: Void 1: Effective
_ X _ _: AI3 power failure detection
0: Void 1: Effective
AI1 power failure
detection threshold
AI1 power failure
detection delay time
AI1 power failure
detection response
0: No action (for non-stop alarm)
1: Forcedly set to the minimum
2: Forcedly set to the maximum
3: Forcedly set to the defaults value
(F4.3.40)
4: Inverter forced trip stop
AI1 power failure default
value
AI2 power failure
detection threshold
AI2 power failure
detection delay time
Action selection after AI2
power failure
0: No action(for non-stop alarm)
1: Forcedly set to the minimum
2: Forcedly set to the maximum
3: Forcedly set to the defaults value
(F4.3.44)
4: Inverter forced trip stop
AI2 power failure default
value
AI3 power failure
detection upper threshold
AI3 power failure
detection lower threshold
AI3 power failure
detection delay time
AI3 power failure
detection response
0: No action(for non-stop alarm)
1: Forcedly set to the minimum
2: Forcedly set to the maximum
3: Forcedly set to the defaults value
(F4.3.49)
4: Inverter forced trip stop
AI3 power failure default
value
