6.2.15 MULTIFUNCTIONAL OUTPUT TERMINAL
Function
Code
Name
Setting Range and
Description
Minimum
Unit
Factory
Default
Change
Limit
F3.1.12
Multifunctional output terminal DO1
0~71
1
1
F3.1.13
Multifunctional output terminal DO2
0~71
1
2
F3.1.14
Multifunctional output terminal DO3/
Fout/standard expansion card
0~71
1
63
F3.1.15
DO1 terminal effective signal output
delay time
0.0~10.00Sec.
0.01
0.0
F3.1.16
DO1 terminal void signal output delay
time
0.0~10.00Sec.
0.01
0.0
F3.1.17
DO2 terminal effective signal output
delay time
0.0~10.00Sec.
0.01
0.0
F3.1.18
DO2 terminal void signal output delay
time
0.0~10.00Sec.
0.01
0.0
F3.1.19
DO3 terminal effective signal output
delay time
0.0~10.00Sec.
0.01
0.0
F3.1.20
DO3 terminal void signal output delay
time
0.0~10.00Sec.
0.01
0.0
F3.1.21
Multifunctional relay output
(RO1A/B/C)
0~71
1
4
F3.1.22
Multifunctional relay output
(RO2A/B/C)/standard expansion card
0~71
1
5
F3.1.23
RO1 power-on delay time
0.0~10.00Sec.
0.01
0.0
F3.1.24
RO1 disconnection delay time
0.0~10.00Sec.
0.01
0.0
F3.1.25
RO2 power-on delay time
0.0~10.00Sec.
0.01
0.0
F3.1.26
RO2 disconnection delay time
0.0~10.00Sec.
0.01
0.0
F3.1.27
Input variable of monitor 1
0~44 (revering to the
monitor variable
comparison table)
1
0
F3.1.28
Input variables of monitor 2
0~44 (referring to the
monitor variable
comparison table)
1
1
F3.1.29
Input variables of monitor 3
0~44 (referring to the
monitor variable
comparison table)
1
2
F3.1.30
Lower limiting value of monitor 1
variables (relative to full scale value
0.0~100.0 (%)
0.1
0.0
F3.1.31
Upper limiting value of monitor 1
variables (relative to full scale value
0.0~100.0 (%)
0.1
100.0
F3.1.32
Lower limiting value of monitor 2
variables (relative to full scale value
0.0~100.0 (%)
0.1
0.0
F3.1.33
Upper limiting value of monitor 2
variables (relative to full scale value
0.0~100.0 (%)
0.1
100.0
F3.1.34
Lower limiting value of monitor 3
variables (relative to full scale value
0.0~100.0 (%)
0.1
0.0
F3.1.35
Upper limiting value of monitor 3
variables (relative to full scale value
0.0~100.0 (%)
0.1
100.0
