6.2.51 HISTORICAL FAULT RECORDING
Function
Code
Name
Setting Range and Description
Minimu
m Unit
Factory
Default
Change
Limit
dE.0.00
Last time fault recording
-
-
-
R/I
dE.0.01
Historical fault 1
-
-
-
R/I
dE.0.02
Historical fault 2
-
-
-
R/I
dE.0.03
Historical fault 3
-
-
-
R/I
dE.0.04
Historical fault 4
-
-
-
R/I
dE.0.05
Historical fault 5
-
-
-
R/I
dE.0.06
Historical fault 6
-
-
-
R/I
dE.0.07
Historical fault 7
-
-
-
R/I
6.2.52 OPERATION STATUS AT THE LAST FAULT
Function
Code
Name
Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
dE.0.08
Operating frequency (rotor
synchronous frequency)
-300.00~300.00Hz
0.01
0
R/I
dE.0.09
Output current
0.0~3000.0A
0.1
0
R/I
dE.0.10
Output voltage
0~1000V
1
0
R/I
dE.0.11
Detection motor revolution
0~30000rpm
1
0
R/I
dE.0.12
Voltage at the DC side
0~1000V
1
0
R/I
dE.0.13
Output torque
-300.0~ 300.0%
0.1%
0
R/I
dE.0.14
Target frequency
0.0~300.00Hz
0.01
0
R/I
dE.0.15
Equipment maximum
temperature
0.0~150.0
0.1°C
0
R/I
dE.0.16
Command status
_ _ _ X:
0: Stop command
1: Running command
_ _ X _: Reserved
_ X _ _: Reserved
X _ _ _: Reserved
1
0000
R/I
dE.0.17
Inverter operation status
_ _ _ X: Operation mode
0: V/F mode
1: Open-loop vector speed
2: Closed-loop vector speed
3: Open-loop torque control
4: Closed-loop torque control
_ _ X _: Operation status
0: Stop
1: Start acceleration
2: Stop deceleration
3: Decreasing frequency and
deceleration
4: Steady operation
_ X _ _: Electric/braking status
1
0000
R/I
