Simphoenix V800 Series - 6.2.22 VIRTUAL ANALOG INPUT; 6.2.23 HOPPING FREQUENCY

Functional Parameter Table
V800 Series High Performance Closed-Loop Vector Inverter User Manual
59
6.2.22 VIRTUAL ANALOG INPUT
Function
Code
Name
Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
F4.4.50
Virtual analog
input SAI1
0: Void (0 value)
1: SAI_COF1*AI1
2: SAI_COF1*AI2
3: SAI_COF1*AI3
4: SAI_COF1*AO1
5: SAI_COF1*AO2
6: SAI_COF1*AI1+SAI_COF2*AI2+SAI_CST
7: SAI_COF1*AI1+SAI_COF2*AI3+SAI_CST
8: SAI_COF1*AO1+SAI_COF2*AO2+SAI_CST
9: SAI_COF1*AI1+SAI_COF2*AO1+SAI_CST
10: SAI_COF1*AI2+SAI_COF2*AO2+SAI_CST
11: SAI_COF1*AI1+SAI_COF2*AO1
12: SAI_COF1*AI3+SAI_COF2*AO2
13: SAI1_COF*AI1/AI2+ SAI_ CST
14: SAI2_COF*AI2/AI3+ SAI_CST
15: SAI1_COF*AI1/AI3+ SAI_CST
1
0
×
F4.4.51
Virtual analog
input SAI2
1
0
×
F4.4.52
Virtual input
combination
coefficient 1
(SAI_COF1)
0.01~500.00
0.01
1.00
×
F4.4.53
Virtual input
combination
coefficient 2
(SAI_COF2)
0.01~500.00
0.01
1.00
×
F4.4.54
Virtual input
combination
constant
(SAI_CST)
-4080~4080
1
0
×
6.2.23 HOPPING FREQUENCY
Function
Code
Name
Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
F5.0.00
Hopping frequency 1
0.0~[F0.1.21]
0.01
0.0
×
F5.0.01
Range of hopping
frequency 1
0.0~10.00Hz
0.01
0.0
×
F5.0.02
Hopping frequency 2
0.0~[F0.1.21]
0.01
0.0
×
F5.0.03
Range of hopping
frequency 2
0.0~10.00Hz
0.01
0.0
×
F5.0.04
Hopping frequency 3
0.0~[F0.1.21]
0.01
0.0
×
F5.0.05
Range of hopping
frequency 3
0.0~10.00Hz
0.01
0.0
×
