Simphoenix V800 Series - 6.2.39 COMPENSATION PID CONTROLLER PARAMETER SELECTION

Functional Parameter Table
V800 Series High Performance Closed-Loop Vector Inverter User Manual
76
Function
Code
Name
Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
input maximum
F9.0.15
Actual value
multiplication factor
0.01~100.00
0.01
1.00
F9.0.16
Sensor value when
actual value is 100%
0.01~100.00
0.01
1.00
F9.0.17
~
F9.0.20
Reserved
6.2.39 COMPENSATION PID CONTROLLER PARAMETER SELECTION
Function
Code
Name
Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
F9.1.21
Selection and switching of
controller parameters
_ _ _ X: PID parameters
0: Single PID parameter
1: Dual PID parameters
2: Three PID parameters
3: Four PID parameters
_ _ X _: PID parameter switching mode
0: As per set value
1: As per feedback value
2: As per output frequency
3: Selected by multifunctional terminal
(Function No.63 and 64)
1
0020
F9.1.22
Controller parameter
switching transition
coefficient
0.01 ~ 50.00
0.01
1.00
F9.1.23
Lower limit for group 1/2
parameter switching
0.0~[F9.1.24]
0.1
0.0
F9.1.24
Upper limit for group 1/2
parameter switching
[F9.1.23]~100.0 (%)
0.1
0.0
F9.1.25
Lower limit for group 2/3
parameter switching
[F9.1.24]~[F9.1.26]
0.1
100.0
F9.1.26
Upper limit for group 2/3
parameter switching
[F9.1.25]~100.0 (%)
0.1
100.0
F9.1.27
Lower limit for group 3/4
parameter switching
[F9.1.26]~[F9.1.28]
0.1
100.0
F9.1.28
Upper limit for group 3/4
parameter switching
[F9.1.27]~100.0 (%)
0.1
100.0
F9.1.29
Proportional gain 2
0.0~100.00
0.01
2.00
F9.1.30
Integration time 2
0.0, 0.01~100.00Sec.
0.01
2.00
F9.1.31
Differential coefficient2
0.0, 0.01~10.00
0.01
0.0
F9.1.32
Differential output filtering
constant 2
0.01~25.00Sec.
0.01
5.00
F9.1.33
Adjuster output filtering
time coefficient 2
0.0, 0.01~20.00Sec.
0.01
1.00
F9.1.34
Proportional gain 3
0.0~100.00
0.01
2.00
