Functional Parameter Table
V800 Series High Performance Closed-Loop Vector Inverter User Manual
80
Function
Code
Name
Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
input terminal EDI5
Fb.0.05
Expand multifunctional
input terminal EDI6
0~96
1
0
×
Fb.0.06
Expand multifunctional
input terminal EDI7
0~96
1
0
×
Fb.0.07
Expand multifunctional
input terminal EDI8
0~96
1
0
×
Fb.0.08
Expand multifunctional
terminal filtering time
1~50ms
1
5ms
Fb.0.09
Expand multi function
input terminal active
level
_ _ _ X: EDI1~EDI4 terminal
0~F: 4-bit binary system, bit=0 power-on
effective, 1 Disconnection Effective LED
_ _ X _: EDI5~EDI8 terminal
The same as above
_ X _ _: Reserved
X _ _ _: Reserved
1
0000
×
6.2.44 EXPANSION MULTIFUNCTIONAL OUTPUT TERMINAL
(ED01/ ERO1~ ED04/ ERO4)/ Effective after Connecting Expanding Accessories
Function
Code
Name
Setting Range and
Description
Minimum
Unit
Factory
Default
Change
Limit
Fb.1.10
Expand multifunctional input terminal EDO1
0~62
1
0
Fb.1.11
Expand multifunctional input terminal EDO2
0~62
1
0
Fb.1.12
Expand multifunctional input terminal EDO3
0~62
1
0
Fb.1.13
Expand multifunctional input terminal EDO4
0~62
1
0
Fb.1.14
Expand multifunctional input terminal ERO1
0~62
1
0
Fb.1.15
Expand multifunctional input terminal ERO2
0~62
1
0
Fb.1.16
Expand multifunctional input terminal ERO3
0~62
1
0
Fb.1.17
Expand multifunctional input terminal ERO4
0~62
1
0
6.2.45 SERVOCONTROL AND SCALE POSITIONING
Function
Code
Name
Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
Fb.2.18
Automatic shift frequency
0~5.00Hz
0.01
1.00
Fb.2.19
Automatic shift switching cycle
0.10~2.00Sec.
0.01
0.30
Fb.2.20
Zero frequency torque holdup
(DC bind-type brake preferred)
0: Void
1: Bind-type brake torque effective
2: Position locking(PG feedback
VC mode)
3: Lock in the designated shutdown
angle
1
0
×
Fb.2.21
Position lock gain1(location
gain)
00.10~10.00
0.01
1.00
Fb.2.22
PG speed shaft propulsion
distance per revolution
0.001~50.000mm
0.01
0.500
