Simphoenix V800 Series - 6.2.54 AUXILIARY STATUS PARAMETER; 6.2.55 MODBUS FIELDBUS STATUS PARAMETER (Standard Expansion Card)

Functional Parameter Table
V800 Series High Performance Closed-Loop Vector Inverter User Manual
90
6.2.54 AUXILIARY STATUS PARAMETER
Function
Code
Name
Setting Range and
Description
Minimum
Unit
Factory
Default
Change
Limit
d0.1.30
Frequency setting source 1 set value
0.0~300.00Hz
0.01Hz
-
R
d0.1.31
Frequency setting source 2 set value
0.0~300.00Hz
0.01Hz
-
R
d0.1.32
Frequency/revolution integrator output
-300.0Hz~300.00Hz
0.01Hz
-
R
d0.1.33
Stator synchronous frequency
-300.0Hz~300.00Hz
0.01Hz
-
R
d0.1.34
Actually measured revolution value
-30000~30000rpm
1rpm
-
R
d0.1.35
Inverter overload integrator value
0 ~ 1020
1
-
d0.1.36
Process PID set variable (physical
quantity)
0.01~60000
0.01
-
R
d0.1.37
Process PID feedback variable
(physical quantity)
0.01~60000
0.01
-
R
d0.1.38
Compensation PID set variable
(physical quantity)
0.01~60000
0.01
-
R
d0.1.39
Compensation PID feedback variable
(physical quantity)
0.01~60000
0.01
-
R
d0.1.40
Torque current
-3000.0~3000.0A
0.1A
-
R
d0.1.41
Excitation current
0.0~3000.0A
0.1A
-
R
d0.1.42
Device body temperature detection 1
0~150.0°C
0.1°C
-
R
d0.1.43
Device body temperature detection 2
0~150.0°C
0.1°C
-
R
d0.1.44
Device body temperature detection 3
0~150.0°C
0.1°C
-
R
d0.1.45
Motor temperature
0~250.0°C
0.1°C
-
R
6.2.55 MODBUS FIELDBUS STATUS PARAMETER (Standard Expansion Card)
Function
Code
Name
Setting Range and
Description
Minimu
m Unit
Factory
Default
Change
Limit
d0.2.46
Bus communication set value 1
-10000~10000
1
R
d0.2.47
Bus communication set value 2
-30000~30000
1
R
d0.2.48
Bus command word 1 (HEX)
0~0FFFFH
1
R
d0.2.49
Bus command word 2 (HEX)
0~0FFFFH
1
R
d0.2.50
Bus status word 1 (HEX)
0~0FFFFH
1
R
d0.2.51
Bus status word 2 (HEX)
0~0FFFFH
1
R
d0.2.52
Total quantity of bus information
0~65535
1
R
d0.2.53
Number of bus CRC check errors
0~65535
1
R
d0.2.54
Number of error data accepted by bus
0~65535
1
R
d0.2.55
Number of effective data of bus
0~65535
1
R
