7.29 PROCESS PID (4MS CONTROL CYCLE) (GROUP F7.0)
F7.0.00 Process PID function
selection
Setting range：0000~2102
Factory default：0000
Process PID works when frequency setting channel (F0.2.25, F0.2.26 value 23) functional, and need set
frequency reference priority selection (F5.3.28) to 0007, then the output of the process PID be as the
frequency command of frequency setting channel, the upper limit of this frequency command will be chosen
by the kilobit of this parameter. This function is mainly applied in occasions of PID output and external set
superposition. Wake up/sleep is invalid in this mode.
X _ _ _: The main and auxiliary superposition mode refer to frequency reference
0: Upper frequency limit
The frequency reference determined by the maximum value of chosen PID function frequency setting
channel。
1: superposition channel set value
The frequency reference determined by the value of unselected PID function frequency setting channel。
2: superposition channel set value/upper frequency-superposition channle setting
When the set value of PID output and superposition channel have the same sign，reference frequency will be
“frequency-superposition channel setting”, otherwise it will be superposition channel set value。
If want wakeup/sleep of process PID functional，the priority of rated output mode must higher than frequency
setting channel. (F5.3.28=0000 or 0001)
F7.0.04 Analog input minimum
value (Channel 1)
Setting range:0.0V~[F7.0.05]/
AI2: 0.0mA~[F7.0.05]
Factory default: 0.0
F7.0.05 Analog input maximum
value (Channel 1)
Setting range:[F7.0.04]~10.00/
AI2: [F7.0.04] ~20.00mA
Factory default: 10.00
F7.0.06 Analog input minimum
value (Channel 2)
Setting range:0.0V~[F7.0.07]/
AI2: 0.0mA~[F7.0.07]
Factory default: 0.0
F7.0.07 Analog input maximum
value (Channel 2)
Setting range:[F7.0.06]~10.00/
AI2: [F7.0.06] ~20.00mA
Factory default: 10.00
When analog channel input is selected for setting source of process PID, corresponding relationship
between set value of process PID and analog port can be altered with this group of parameters. The
corresponding relationship is shown in Figure 7-52.
F7.0.12 Actual value 1 minimum
(feedback channel 1)
Setting range: 0.0~[F7.0.13]/
AI2: 0.0mA~[F7.0.13]
Factory default: 0.0
F7.0.13 Actual value 1 maximum
(feedback channel 1)
Setting range: [F7.0.12]~10.00V/
AI2:[F7.0.12] ~20.00mA
Factory default: 5.00
F7.0.14 Actual value 2 minimum
(feedback channel 2)
Setting range: 0.0~[F7.0.15]/
AI2: 0.0mA~[F7.0.15]
Factory default: 0.0
F7.0.15 Actual value 2 maximum
( feedback channel 2)
Setting range: [F7.0.14]~10.00V/
AI2: [F7.0.14] ~20.00mA
Factory default: 5.00
When the analog channel input is selected for feedback source of process PID, corresponding relationship
