V800 Series High Performance Closed-Loop Vector Inverter User Manual
2. Parameter Configuration of DC Reactor
Inverter Power
(KW)
Reactor Model
Size L*W*H (mm)
Mounting
Dimension
(mm)
Terminal
Aperture
(mm)
0.7
DLK-3A
80*65*110
63*60
Φ4
1.1
DLK-6A
80*85*110
63*60
Φ4
1.5
DLK-6A
80*85*110
63*60
Φ4
2.2
DLK-6A
80*85*110
63*60
Φ4
3.0
DLK-12A
100*100*125
80*70
Φ4
4.0
DLK-12A
100*100*125
80*70
Φ4
5.5
DLK-23A
110*120*135
87*70
Φ4
7.5
DLK-23A
110*120*135
87*70
Φ4
9.0
DLK-33A
110*120*135
87*70
Φ4
11
DLK-33A
110*120*135
87*70
Φ4
15
DLK-33A
110*120*135
87*70
Φ4
18.5
DLK-40A
110*120*135
87*70
Φ5
22
DLK-50A
120*135*145
95*85
Φ5
30
DLK-65A
138*150*170
111*85
Φ5
37
DLK-78A
138*150*170
111*85
Φ5
45
DLK-95A
138*150*170
111*85
Φ6
55
DLK-115A
155*160*195
125*90
Φ6
12.4.3 INPUT REACTOR
AC input reactor is mounted at input terminal of inverter to restrain transmitting harmonic
generated by inverter to power grid, reduce interference of inverter harmonic to other
components, improve quality of power grid, improve power factors and restrain
abnormal fluctuations of power grid voltage and surge current of power grid, stabilize
waveform and reduce impact to inverter.
1. Performance index of AC input reactor
● Rated operational voltage: 380V/50Hz；
● Dielectric strength: iron core-winding 3000VAC/50Hz/5mA/60S, no flashover breakdown；
