Simphoenix V800 Series - 6.2.20 ANALOG OUTPUT

Functional Parameter Table
V800 Series High Performance Closed-Loop Vector Inverter User Manual
57
6.2.20 ANALOG OUTPUT
Function
Code
Name
Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
F4.2.22
AO1 mapping variable
(subjecting to F5.4.44
exceeding function )
0~45(monitor variable comparison
table)
1
0
F4.2.23
AO2 mapping
variable/standard
expansion card
0~45 (monitor variable comparison
table)
1
2
F4.2.24
AO1 mini value
0.00~10.00V
0.01
0.0
F4.2.25
AO1 max value
0.00~10.00V
0.01
10.00
F4.2.26
AO1 lower limiting value
0.0~[F4.2.27]
0.1
0.0
F4.2.27
AO1 upper limiting value
[F4.2.26]~100.0 (%)
0.1
100.0
F4.2.28
AO1 filtering time
coefficient
0.01~10.00Sec.
0.01
0.10
F4.2.29
AO1 fixed output value
(at the time of fixed
output value)
0.0~20.00mA (0.0~10.00V)
0.01
0.0
F4.2.30
AO2 min value
0.00~10.00V
0.01
0.0
F4.2.31
AO2 max value
0.00~10.00V
0.01
10.00
F4.2.32
AO2 lower limiting value
0.0~[F4.2.33]
0.1
0.0
F4.2.33
AO2 upper limiting value
[F4.2.32]~100.0 (%)
0.1
100.0
F4.2.34
AO2 filtering time
coefficient
0.01~10.00Sec.
0.01
0.10
F4.2.35
AO2 fixed output value
(at the time of fixed
output value)
0.0~20.00mA (0.0~10.00V)
0.01
0.0
