Functional Parameter Table
V800 Series High Performance Closed-Loop Vector Inverter User Manual
6.2.33 PROCESS PID SLEEP FUNCTION
(Effective when PID output is used as the frequency command)
Setting Range and Description
0: Closed 1: Enabled
2: Enabled when the multifunctional input
selection is effective (Function No. 33)
Awakening deviation
(compared with the
set value )
6.2.34 REVOLUTION SETTING AND FEEDBACK
Setting Range and Description
Revolution setting
channel (only applicable
to VC and SVC mode)
0: Set by frequency setting parameter
(F0.1.16)
1: Digital setting (F8.0.03) (maintained
after stop and saved after power-off)
2: Keypad potentiometer
3: Analog inputAI1
4: Analog inputAI2
5: Analog inputAI3 (dual polarity)
6: Frequency input (Fin)
7: MODBUS Fieldbus set value 1
8: MODBUS Fieldbus set value 2
9: Virtual analog input SAI1
10: Virtual mode input SAI2
Minimum set signal
corresponding revolution
0~60*[F0.1.21] /
pairs of motor poles (rpm)
Maximum set signal
corresponding revolution
0~60*[F0.1.21] /
pairs of motor poles (rpm)
Revolution Digital setting
0~60*[F0.1.21] /
pairs of motor poles (rpm)
Revolution feedback
channel
0: Decoder (PG card needs to be
equipped)
1: Single pulse input (Fin port)
2: Analog input AI1
3: Analog input AI2
4: Analog input AI3 (dual polarity)
Pulse of decoder per
revolution (PG)
PG rotation direction
(Effective for PG card)
0: Phase A leads
1: Phase B leads
