Description Of Specific Functions
V800 Series High Performance Closed-Loop Vector Inverter User Manual
182
Register Name
Access address
Remarks
Mapping application parameter 2
0x1304
The access parameter is set by FA.1.09.
Mapping application parameter 3
0x1305
The access parameter is set by FA.1.10
Mapping application parameter 4
0x1306
The access parameter is set by FA.1.11.
Mapping application parameter 5
0x1307
The access parameter is set by FA.1.12.
Mapping application parameter 6
0x1308
The access parameter is set by FA.1.13.
Status word
0x1309
Can be read as per the discrete quantity (1~16)
Mapping status parameter 1
0x130A
The access parameter is set by FA.1.14.
Mapping status parameter 2
0x130B
The access parameter is set by FA.1.15.
Mapping status parameter 3
0x130C
The access parameter is set by FA.1.16.
Mapping status parameter 4
0x130D
The access parameter is set by FA.1.17.
Mapping status parameter 5
0x130E
The access parameter is set by FA.1.18.
Mapping status parameter 6
0x130F
The access parameter is set by FA.1.19.
Mapping status parameter 7
0x1310
The access parameter is set by FA.1.20.
Mapping status parameter 8
0x1311
The access parameter is set by FA.1.21.
Mapping status parameter 9
0x1312
The access parameter is set by FA.1.22.
Mapping status parameter 10
0x1313
The access parameter is set by FA.1.23.
The mapping parameters are determined by FA.1 group of parameters.
For example, in one frame of standard MODBUS protocol data, it’s impossible to read the status parameters
d0.0.02, d0.0.05, d1.0.01 and d1.1.31 and status word once and for all with a common method. To map
status parameters into the bus-controlled parameter area with continuous address, set with the following
method:
[FA.1.14] = d0.02
[FA.1.15] = d0.05
[FA.1.16] = d1.01
[FA.1.17] = d1.31
Then you it just needs to read the data in the continuous address 0x130A ~ 0x130D.
7.40 COMMUNICATION LINKAGE SYNCHRONOUS CONTROL
(GROUP FA.2)
FA.2.26 Linkage setting proportion
coefficient
Setting Range: 0.010~10.000
Factory Default: 1.000
During linkage control, this parameter defines the proportion between the output frequency of the master
machine and the slave machine; the parameter of the master inverter does not function.
FA.2.27 Coupling fine proportion
adjustment
Setting range: 0~3
Factory default: 0
0: No fine adjustment
If the fine adjustment source for linkage proportion coefficient is void, then: Slave frequency command =
