6.2.12 VECTOR RUNNING PARAMETERS (MOTOR 2)
Function
Code
Name
Setting Range and Description
Minimum
Unit
Factory
Default
Chang
e Limit
F2.1.26
Rated power
0.1~1000.0KW
0.1 KW
☆
×
F2.1.27
Rated voltage
30~480V
1V
380/22
0
×
F2.1.28
Rated current
0.01~650.00A
0.01A
☆
×
F2.1.29
Rated frequency
max{5.00,[F2.1.30]/60}~300.00Hz
0.01Hz
50.00
×
F2.1.30
Rated revolution
10~min.{30000,60* [F2.1.29]}rpm
1rpm
☆
×
F2.1.31
Idling current
0.15*[F2.1.28]~0.8* [F2.1.28]
0.01A
☆
×
F2.1.32
Stator resistance
0.01~65000mΩ
☆
☆
×
F2.1.33
Stator inductance
0.001~6500.0mH
☆
☆
×
F2.1.34
Total leakage
inductance
0.001~6500.0mH
☆
☆
×
F2.1.35
Rotator time constant
5.0~6500.0ms
0.1ms
☆
×
F2.1.36
Slip compensation
coefficient
0.25~2.00
0.01
1.00
F2.1.37
~F2.1.49
Retention parameter
×
F2.1.50
Z pulse initial angle
0.0~359.9
0.1
0.0
×
F2.1.51
Motor overload
protection coefficient
50.0~131.0(%) (131—closed)
0.1
110.0
F2.1.37
Rated torque of PMSM
0.1~6553.5NM
0.1NM
☆
×
F2.1.38
Rated voltage of
PMSM
30~480V
1V
380/22
0
×
F2.1.39
Rated current of PMSM
0.1~650.0A
0.1A
☆
×
F2.1.40
Rated frequency of
PMSM
5.00~300.00Hz
0.01Hz
50.00
×
F2.1.41
Rated revolution of
PMSM
10~30000rpm
1
1500
×
F2.1.42
Back EMF coeffcient of
PMSM
1.0~2000.0V/1000rpm
0.1
207.0
×
F2.1.43
Torque coeffcient of
PMSM
0.10~500.00 Nm/A
0.01
3.00
×
F2.1.44
Identification current of
PMSM
1.0~80.0%
0.1
25.0
×
F2.1.45
Stator resistance of
PMSM
0.01~65000mΩ
☆
×
F2.1.46
Vertical axis inductance
of PMSM
0.001~6500.0mH
☆
×
F2.1.47
Quadrature axis
inductance of PMSM
0.001~6500.0mH
☆
×
F2.1.48
Initial angle of PMSM
0~65535
1
0
×
F2.1.49
Z pulse original angle
0.0~359.9
0.1
0.0
×
F2.1.50
reserved
reserved
-
-
×

The stator resistance, stator inductance and the Minimum Unit of total leakage inductance
of asynchronous motors is relevant with different models.
