Simphoenix V800 Series - 6.2.41 MAPPING ACCESS PARAMETER; 6.2.42 COMMUNICATION LINKAGE SYNCHRONOUS CONTROL (GROUP FA.2)

Functional Parameter Table
V800 Series High Performance Closed-Loop Vector Inverter User Manual
78
Function
Code
Name
Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
failure judging time
FA.0.05
Communication
failure action
0: Deceleration stop
1: Run as per last received command
1
0
FA.0.06
Selection of
communication
configuration files
0: SUNFAR standard configuration file 1
1: SUNFAR standard configuration file 2
(Reserved)
1
0
FA.0.07
——
——
6.2.41 MAPPING ACCESS PARAMETER
Function
Code
Name
Setting Range and
Description
Minimum
Unit
Factory
Default
Change
Limit
FA.1.08
Mapping application parameter 1 (H)
F0.00 ~ FF.55
1
F0.29
×
FA.1.09
Mapping application parameter 2 (H)
F0.00 ~ FF.55
1
F0.29
×
FA.1.10
Mapping application parameter 3 (H)
F0.00 ~ FF.55
1
F0.29
×
FA.1.11
Mapping application parameter 4 (H)
F0.00 ~ FF.55
1
F0.32
×
FA.1.12
Mapping application parameter 5 (H)
F0.00 ~ FF.55
1
F0.32
×
FA.1.13
Mapping application parameter 6 (H)
F0.00 ~ FF.55
1
F0.32
×
FA.1.14
Mapping status parameter 1 (H)
d0.00 ~ d1.55
1
d0.00
FA.1.15
Mapping status parameter 2 (H)
d0.00 ~ d1.55
1
d0.01
FA.1.16
Mapping status parameter 3 (H)
d0.00 ~ d1.55
1
d0.02
FA.1.17
Mapping status parameter 4 (H)
d0.00 ~ d1.55
1
d0.03
FA.1.18
Mapping status parameter 5 (H)
d0.00 ~ d1.55
1
d0.04
FA.1.19
Mapping status parameter 6 (H)
d0.00 ~ d1.55
1
d0.05
FA.1.20
Mapping status parameter 7 (H)
d0.00 ~ d1.55
1
d0.06
FA.1.21
Mapping status parameter 8 (H)
d0.00 ~ d1.55
1
d0.07
FA.1.22
Mapping status parameter 9 (H)
d0.00 ~ d1.55
1
d0.08
FA.1.23
Mapping status parameter 10 (H)
d0.00 ~ d1.55
1
d0.09
FA.1.24
—
—
—
—
6.2.42 COMMUNICATION LINKAGE SYNCHRONOUS CONTROL
Function
Code
Name
Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
FA.2.25
Coupling synchronous
control options
_ _ _ X: Selection of coupling
function
0: Void
1: The device is the salve device
2: The device is the master device
_ _ X _: Linkage target value (Master
device parameter)
0: Proportional linkage of frequency
/revolution set value
1: Proportional linkage of frequency
/revolution integrator output value
1
0310
×
