Simphoenix V800 Series - 3.4 INSTALLATION SIZE OF PANEL

Installation Of Frequency Inverter
V800 Series High Performance Closed-Loop Vector Inverter User Manual
15
3.4 INSTALLATION SIZE OF PANEL(Operation panel is optional in
accordance to the installation need.)
name
Double line LED panel
Double line LED standard operation panel/
double line LED operation panel（shuttle type）
Installation
size
22
55
30
51
101
25
105
66
46.5
130
70
126
2350
27
external
installation
without the
tray
The trepanning of mounting plate as follow;
size : 102*52
102
mounting
plate
52
The trepanning of mounting plate as follow;
size : 127*67
67
127
mounting
plate
External
installation
with a tray
No such connection
The trepanning of mounting plate as follow
91
95
72
125
5
mounting plate
screw
fixation
10
4
-
t
h
r
o
u
g
h
h
o
l
e
