6.2.31 PROCESS PID (4MS CONTROL CYCLE)
Function
Code
Name
Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
F7.0.00
Process PID function
selection
_ _ _ X: Process PID controller selection
0: Process PID closed
1: Unconditionally effective
2: External multifunctional terminal
selectivity effective (Function No. 22)
_ _ X _: Reserved
_ X _ _: Process PID controller output
0: Frequency/revolution set value
1: Independent PID (created by AO terminal
output or as a torque)
X_ _ _: Superposition mode of main and
auxiliary, consult the frequency
benchmark
0: Upper limit of frequency channel
1: Set value of superposition channel
2: Set value of superposition channel/
upper limit frequency-superposition
channel set
1
0000
×
F7.0.01
Process PID set value
selection
0: PID Reference Channel 1
1: PID Reference Channel 2
2: Select Channel Via Terminal (Function
No. 31)
3: Channel 1 + Channel 2
4: Channel 1 - Channel 2
5: Channel 1 * (1+ Channel 2/100.0)
6: Channel 1 * (1- Channel 2/100.0)
7: Channel 1 * Channel 2/100.0
1
0
F7.0.02
Process PID setting
channel 1
0: PID Internal Reference (F7.0.08)
(power-off save)
1: Keypad Potentiometer
2: Analog input AI1
3: Analog input AI2
4: Analog input AI3
5: Remote UP/DW 1 (clear after stop)
6: Remote UP/DW 2 (maintained after stop
and saved after power-off)
7: Analog input AI3
8: Remote UP/DW 3(clear after stop)
9: U Remote UP/DW 4 (maintained after
stop and saved after power-off)
10: MODBUS value 1
11: MODBUS value 2
1
0
×
F7.0.03
Process PID setting
channel 2
1
0
×
F7.0.04
Analog input quantity
corresponding to 0%
setting (Channel 1)
0.0V~[F7.0.05]/ AI2: 0.0mA~[F7.0.05]
0.01
0.0
F7.0.05
Analog input quantity
corresponding to
100% setting
(Channel 1)
[F7.0.04]~10.00/AI2: [F7.0.04]~20.00mA
0.01
10.00
