Simphoenix V800 Series - 6.2.13 PARAMETER MEASUREMENT AND PRE-EXCITATION; 6.2.14 MULTIFUNCTIONAL INPUT TERMINAL

Functional Parameter Table
V800 Series High Performance Closed-Loop Vector Inverter User Manual
53
6.2.13 PARAMETER MEASUREMENT AND PRE-EXCITATION
Function
Code
Name
Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
F2.2.52
Start excitation time in
vector mode
0.02~2.50Sec.
0.01
☆
F2.2.53
Motor parameter
measurement
0: Closed
1: Static identification
2: Static + operating parameter
identification
3: Static + operating parameter
identification + revolution ratio
identification
1
0
×
6.2.14 MULTIFUNCTIONAL INPUT TERMINAL
Function
Code
Name
Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
F3.0.00
Multifunctional input
terminal DI1
0~96
1
0
×
F3.0.01
Multifunctional input
terminal DI2
0~96
1
0
×
F3.0.02
Multifunctional input
terminal DI3
0~96
1
7
×
F3.0.03
Multifunctional input
terminal DI4
0~96
1
8
×
F3.0.04
Multifunctional input
terminal DI5
0~96
1
13
×
F3.0.05
Multifunctional input
terminal DI6
0~96
1
0
×
F3.0.06
Multifunctional input
terminal DI7/
standard expansion card
0~96
1
0
×
F3.0.07
Multifunctional input
terminal DI8 /
standard expansion card
0~96
1
0
×
F3.0.08
Multifunctional input
terminal DI9/Fin/
standard expansion card
0~98
1
97
×
F3.0.09
Multifunctional terminal
filtering time (DI1~DI5)
1~50ms
1
5ms
F3.0.10
Multifunctional terminal
filtering time (DI6~DI9)
/standard expansion card
1~50ms
1
5ms
F3.0.11
Input terminal effective
level (H)
_ _ _ X: DI1~DI4 terminal
0~F: 4-bit binary, bit=0 power-on
effective, 1 disconnection effective
_ _ X _: DI5~DI8 terminal
The same as above
_ X _ _: DI9 terminal
The same as above
X _ _ _: Reserved
1
0000
×
