Functional Parameter Table
V800 Series High Performance Closed-Loop Vector Inverter User Manual
81
Function
Code
Name
Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
Fb.2.23
Servo control function
_ _ _ X: Function selection
0: Void
1: Effective
2: External terminal selection
(Function No.69)
_ _ X _: Action mode
0: Common mode
1: Spindle orientation
1
0000
×
Fb.2.24
Position setting source in
common mode
0: Reserved
1: Fin input
2: Digital setting
3: Analog inputAI1
4: MODBUS bus set value 1
5: MODBUS bus set value 2
1
1
Fb.2.25
Position digital setting (lower)
0~65535
1
0
Fb.2.26
Position digital setting (upper)
0~500
1
0
Fb.2.27
Electronic gear (numerator)
0~65535
1
1000
Fb.2.28
Electronic gear (denominator)
0~65535
1
1000
Fb.2.29
Position command filtering time
coefficient
1~1000.0ms
1
10
Fb.2.30
Position gain 2
0.01~100.00
0.01
1.00
Fb.2.31
Position gain selection
0: Gain 1 Effective
1: Gain 2 Effective
2: External terminal selection
(Function No. 75)
3: Position deviation selection
1
0
Fb.2.32
Position gain selected threshold
value (Position deviation)
0~30000
1
10
Fb.2.33
Speed feed-FWD gain
0.0~200.0 (%)
0.1
100.0
Fb.2.34
Rotate speed regulating in
common servo mode
0: Limit by the upper frequency
1: Minimax between the frequency
set channel and position loop
control
1
0
Fb.2.35
——
——
Fb.2.36
Spindle orientation mode
_ _ _ X: Selection of
reference signal for
positioning zero point
0: Z pulse positioning
1: Photoelectric switch
positioning(Function No. 70)
_ _ X _: Command
0: External terminal selection
1: Pulse command setting(Fin)
_ X _ _: Direction arrival
0: Locate according to the order
1: Locate according to the minimum
corner
1
0000
×
