Functional Parameter Table
V800 Series High Performance Closed-Loop Vector Inverter User Manual
61
Function
Code
Name
Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
F5.1.15
Timer door control
signal selection
_ _ _ X: Timer 1(UT1) gated signal
0: No gating function
1: Multifunctional terminal (Function No. 58)
2: Timer 1 comparative value reached
(effective for UT2, UT3)
3: Timer 1 cycle reached (effective for UT2,
UT3)
4: Timer 2 comparative value reached
(effective for UT3)
5: Timer 2 cycle reached (effective for UT3 )
_ _ X _: Timer 2 (UT2) gated signal
selection
The same as above,
1: Multifunctional terminal (Function No. 59)
_ X _ _: Timer 3 (UT3) gated signal
selection
The same as above,
1: Multifunctional terminal (Function No. 60)
1
0000
F5.1.16
Timer 1 output signal
(H)
_ _ _ X: Output signal1
0: Comparative value reached (0.5s pulse)
1: Comparative value reached (level)
2: Comparative value reached and reversed
3: Cycle reached (0.5s pulse)
4: Cycle reached (level)
5: Cycle reached and reversed
6: Comparative value or cycle reached and
reversed
_ _ X _: Output signal 2
The same as above
_ X _ _: Reserved
X _ _ _: Reserved
1
0041
F5.1.17
Timer 2 output signal
(H)
1
0041
F5.1.18
Timer 3 output signal
(H)
1
0041
F5.1.19
Timer value display
unit(H)
_ _ _ X: Timer 1
0: Clock unit (original value)
1: Sec. 2: Min. 3: H.
_ _ X _: Timer 2
The same as above
_ X _ _: Timer 3
The same as above
1
0000
