Description Of Communication Protocol
V800 Series High Performance Closed-Loop Vector Inverter User manual
2) Discrete Input Address Summary (0x1100 ~ 0x1200)
Relevant Modbus functional codes: 0x02 (read input status)
Status Character – Digit 0
Status Character – Digit 1
Status Character – Digit 2
Status Character – Digit 3
Status Character – Digit 4
Status Character – Digit 5
Status Character – Digit 6
Status Character – Digit 7
Status Character – Digit 8
Status Character – Digit 9
Status Character – Digit 10
Status Character – Digit 11
Status Character – Digit 12
Status Character – Digit 13
Status Character – Digit 14
Status Character – Digit 15
Multi-purpose input terminal 1
Multi-purpose input terminal 2
Multi-purpose input terminal 3
Multi-purpose input terminal 4
Multi-purpose input terminal 5
Multi-purpose input terminal 6
Multi-purpose input terminal 7 (extendable card)
Multi-purpose input terminal 8 (extendable card)
Multi-purpose input terminal 9 (extendable card)
