Accessories
233
V800 Series High Performance Closed-Loop Vector Inverter User Manual
D---- braking frequency (time proportion of regeneration process accounts for the whole
process), generally it is 10%. Please refer to table below:
Type
Lift
Winding &
unwinding
Centrifuge
Accidental
braking load
Proportion
20%~30%
20%~30%
50%~60%
5%
Brake resistance selection table
If need braking function of the model upon V560-4T0220, please refer to the braking unit manual.
Model
Adaptive
motor
（KW）
Power of
brake
resistance
(KW)
Brake
resistance
value
（Ω）
Brake
torque
(100%)
Brake unit
V800-4T0011G/4T0015P
1.1
0.3
≥400
100
Standard
V800-4T0015G/4T0022P
1.1
0.3
≥400
100
Standard
V800-4T0022G/4T0030P
1.5
0.5
≥300
100
Standard
V800-4T0030G/4T0040P
2.2
0.65
≥200
100
Standard
V800-4T0040G/4T0055P
3.0
0.75
≥150
100
Standard
V800-4T0055G/4T0075P
4.0
1.0
≥125
100
Standard
V800-4T0075G/4T0090P
5.5
1.5
≥85
100
Standard
V800-4T0090G/4T0110P
7.5
2.0
≥65
100
Standard
V800-4T0110G/4T0150P
9.0
2.5
≥60
100
Standard
V800-4T0150G/4T0185P
11
2.5
≥50
100
Standard
V800-4T0185G/4T0220P
15
3.6
≥35
100
Standard
V800-4T0220G/4T0300P
18.5
4.5
≥30
100
Standard
V800-4T0011G/4T0015P
22
5.5
≥25
100
Standard
