Wiring Of Frequency Inverter
V800 Series High Performance Closed-Loop Vector Inverter User Manual
23
Main loop screw specification/ tightening torque, as listed below
VFD model
Screw specification
Tightening torque(N*m)
V800-4T0011G/4T0015P
M3.5
0.7~0.9
V800-4T0015G/4T0022P
M3.5
0.7~0.9
V800-4T0022G/4T0030P
M3.5
0.7~0.9
V800-4T0030G/4T0040P
M4
1.2~1.5
V800-4T0040G/4T0055P
M4
1.2~1.5
V800-4T0055G/4T0075P
M4
1.2~1.5
V800-4T0075G/4T0090P
M4
1.2~1.5
V800-4T0090G/4T0110P
M4
1.2~1.5
V800-4T0110G/4T0150P
M4
1.2~1.5
V800-4T0150G/4T0185P
M5
2~2.5
V800-4T0185G/4T0220P
M5
2~2.5
V800-4T0220G/4T0300P
M6
4~6
V800-4T0300G/4T0370P
M6
4~6
V800-4T0370G/4T0450P
M8
9~11
V800-4T0450G/4T0550P
M8
9~11
V800-4T0550G/4T0750P
M8
9~11
V800-4T0750G/4T0900P
M10
18~23
V800-4T0900G/4T1100P
M10
18~23
V800-4T1100G/4T1320P
M10
18~23
V800-4T1320G/4T1600P
M10
18~23
V800-4T1600G/4T1850P
M10
18~23
V800-4T1850G/4T2000P
M10
18~23
V800-4T2000G/4T2200P
M12
25~30
V800-4T2200G/4T2500P
M12
25~30
V800-4T2500G/4T2800P
M12
25~30
V800-4T2800G/4T3150P
M16
40~50
V800-4T3150G/4T3500P
M16
40~50
V800-4T3500G/4T4000P
M12
25~30
V800-4T4000G/4T4500P
M12
25~30
V800-4T4500G/4T5000P
M12
25~30
V800-4T5000G/4T5600P
M12
25~30
V800-4T5600G/4T6300P
M16
40~50
V800-4T6300G/4T7000P
M16
40~50
V800-4T7000G/4T8000P
M16
40~50
V800-4T8000G/4T9000P
M16
40~50
General control terminal
Screw specification
Tightening torque(N*m)
control board/extension card terminal
M2
0.1~0.2
control board/extension card terminal
M3
0.3~0.4

The power of adaptive motor can be increased by one power grade when V800 series
frequency inverter is connected with loads for fans and water pumps compared with that
for connecting with general loads.
