Functional Parameter Table
V800 Series High Performance Closed-Loop Vector Inverter User Manual
47
Function
Code
Name
Setting Range and Description
Minimum
Unit
Factory
Default
Change
Limit
1: Deceleration stop
F0.4.38
Start/Stop Mode(H)
_ _ _ X: Start mode
0: Normal start
1: Revolution tracking start
_ _ X _: Reserved
_ X _ _: Stop mode
0: Deceleration stop
1: Free stop
1
0000
×
F0.4.39
Start frequency
0.0~50.00Hz
0.01
0.50
F0.4.40
Start frequency holding
time
0.00~10.00Sec.
0.01
0.0
F0.4.41
Start pre-excitation
current
0.0~100.0(%)
0.1
35.0
F0.4.42
Start pre-excitation
time
0.00~10.00Sec.
0.01
0.10
F0.4.43
Start delay
0.00~10.00Sec.
0.01
0.0
F0.4.44
DC band-type brake
control
_ _ _ X: DC band-type brake function
0: Closed
1: Open
_ _ X _: Reserved
1
0
F0.4.45
DC band type
brake/brake initial
frequency / speed
0.0~[F0.1.21]
0.01
2.00
F0.4.46
DC brake action time
0.0~10.00Sec.
0.01
0.0
F0.4.47
DC band-type
brake/brake injection
current
0.0~100.0(%)
0.1
50.0
F0.4.48
Restart after power-off
0: Forbidden 1: Effective
1
0
F0.4.49
Standby time for restart
after power-off/free
stop
0.1~10.0Sec.
0.1
0.5
F0.4.50
FWD and REV
transition dead time
0.00~5.00Sec.
0.01
0.00
F0.4.51
FWD and REV switch
mode
0: Switch at zero point
1: Start frequency switch
1
0
F0.4.52
Zero speed (frequency)
detection level
0.00~100.00Hz
0.01
0.10 Hz
F0.4.53
Zero speed delay time
0.00~10.00Sec.
0.01
0.05
F0.4.54
Emergency stop mode
(EMS)
0: The inverter will stop in deceleration
mode according to the emergency stop
and deceleration time.
1: The inverter will immediately lock output
and the motor will stop in free sliding
mode.
1
0
