U
SER
A
UTHENTICATION
3-69
CLI – This example shows the default global setting for 802.1X.
Configuring 802.1X Global Settings
The 802.1X protocol includes port authentication. The 802.1X protocol
must be enabled globally for the switch system before port settings are
active.
Command Attributes
• 802.1X System Authentication Control – Sets the global setting for
802.1X. (Default: Disabled)
Web – Select Security, 802.1X, Configuration. Enable 802.1X globally for
the switch, and click Apply.
Figure 3-31 802.1X Configuration
Console#show dot1x 4-115
Global 802.1X Parameters
system-auth-control: enable
802.1X Port Summary
Port Name Status Operation Mode Mode Authorized
1/1 disabled Single-Host ForceAuthorized n/a
1/2 disabled Single-Host ForceAuthorized n/a
.
.
.
802.1X Port Details
802.1X is disabled on port 1/1
802.1X is disabled on port 26
.
.
.
Console#
