3-103
Displaying LACP Port Counters
You can display statistics for LACP protocol messages.
Web – Click Port, LACP, Port Counters Information. Select a member
port to display the corresponding information.
Figure 3-45 LACP - Port Counters Information
Table 3-6 LACP Port Counters
Field Description
LACPDUs Sent Number of valid LACPDUs transmitted from this
channel group.
LACPDUs Received Number of valid LACPDUs received on this channel
group.
Marker Sent Number of valid Marker PDUs transmitted from this
channel group.
Marker Received Number of valid Marker PDUs received by this channel
group.
LACPDUs Unknown
Pkts
Number of frames received that either (1) Carry the
Slow Protocols Ethernet Type value, but contain an
unknown PDU, or (2) are addressed to the Slow
Protocols group MAC Address, but do not carry the
Slow Protocols Ethernet Type.
LACPDUs Illegal Pkts Number of frames that carry the Slow Protocols
Ethernet Type value, but contain a badly formed PDU
or an illegal value of Protocol Subtype.
