C
OMMAND
L
INE
I
NTERFACE
4-234
Default Setting
The DSCP default values are defined in the following table. Note that
all the DSCP values that are not specified are mapped to CoS value 0.
Command Mode
Interface Configuration (Ethernet, Port Channel)
Command Usage
• The precedence for priority mapping is IP Port, IP Precedence or IP
DSCP, and default switchport priority.
• DSCP priority values are mapped to default Class of Service values
according to recommendations in the IEEE 802.1p standard, and
then subsequently mapped to the four hardware priority queues.
• This command sets the IP DSCP priority for all interfaces.
Example
The following example shows how to map IP DSCP value 1 to CoS value
0:
Table 4-62 IP DSCP to CoS Values
IP DSCP Value CoS Value
00
81
10, 12, 14, 16 2
18, 20, 22, 24 3
26, 28, 30, 32, 34, 36 4
38, 40, 42 5
48 6
46, 56 7
Console(config)#interface ethernet 1/5
Console(config-if)#map ip dscp 1 cos 0
Console(config-if)#
