C
ONFIGURING
THE
S
WITCH
3-154
Web – Click VLAN, 802.1Q VLAN, Static Table. Select a VLAN ID from
the scroll-down list. Modify the VLAN name and status if required. Select
the membership type by marking the appropriate radio button in the list of
ports or trunks. Click Apply.
Figure 3-64 Configuring a VLAN Static Table
CLI – The following example adds tagged and untagged ports to
VLAN 2.
Adding Static Members to VLANs (Port Index)
Use the VLAN Static Membership by Port menu to assign VLAN groups
to the selected interface as a tagged member.
Command Attributes
• Interface – Port or trunk identifier.
Console(config)#interface ethernet 1/1 4-146
Console(config-if)#switchport allowed vlan add 2 tagged 4-206
Console(config-if)#exit
Console(config)#interface ethernet 1/2
Console(config-if)#switchport allowed vlan add 2 untagged
Console(config-if)#exit
Console(config)#interface ethernet 1/13
Console(config-if)#switchport allowed vlan add 2 tagged
