C
ONFIGURING
THE
S
WITCH
3-104
CLI – The following example displays LACP counters.
Displaying LACP Settings and Status for the Local Side
You can display configuration settings and the operational state for the
local side of an link aggregation.
Console#show lacp counters 4-173
Port channel : 1
-------------------------------------------------------------------
Eth 1/ 1
-------------------------------------------------------------------
LACPDUs Sent: 91
LACPDUs Receive: 43
Marker Sent: 0
Marker Receive: 0
LACPDUs Unknown Pkts: 0
LACPDUs Illegal Pkts: 0
.
.
.
Console#
Table 3-7 LACP Internal Configuration Information
Field Description
Oper Key Current operational value of the key for the aggregation port.
Admin Key Current administrative value of the key for the aggregation port.
LACPDUs
Internal
Number of seconds before invalidating received LACPDU
information.
LACP System
Priority
LACP system priority assigned to this port channel.
