C
ONFIGURING
THE
S
WITCH
3-108
Web – Click Port, LACP, Port Neighbors Information. Select a port
channel to display the corresponding information.
Figure 3-47 LACP - Port Neighbors Information
CLI – The following example displays the LACP configuration settings
and operational state for the remote side of port channel 1.
Console#show lacp 1 neighbors 4-173
Port channel 1 neighbors
-------------------------------------------------------------------
Eth 1/1
-------------------------------------------------------------------
Partner Admin System ID: 32768, 00-00-00-00-00-00
Partner Oper System ID: 3, 00-30-F1-CE-2A-20
Partner Admin Port Number: 5
Partner Oper Port Number: 3
Port Admin Priority: 32768
Port Oper Priority: 128
Admin Key: 0
Oper Key: 120
Admin State: defaulted, distributing, collecting,
synchronization, long timeout,
Oper State: distributing, collecting, synchronization,
aggregation, long timeout, LACP-activity
.
.
.
Console#
