C
OMMAND
L
INE
I
NTERFACE
4-230
Default Setting
Disabled
Command Mode
Global Configuration
Command Usage
The precedence for priority mapping is IP Port, IP Precedence or IP
DSCP, and default switchport priority.
Example
The following example shows how to enable TCP/UDP port mapping
globally:
map ip port (Interface Configuration)
This command set IP port priority (i.e., TCP/UDP port priority). Use the
no form to remove a specific setting.
Syntax
map ip port port number cos cos-value
no map ip port port-number
- port-number - 16-bit TCP/UDP port number.(Range 1-65535)
- cos-value - Class-of-Service value. (Range: 0-7)
Default Setting
None
Command Mode
Interface Configuration (Ethernet, Port Channel)
Command Usage
• The precedence for priority mapping is IP Port, IP Precedence or IP
DSCP, and default switchport priority.
• This command sets the IP port priority for all interfaces.
Console(config)#map ip port
Console(config)#
