P
RIORITY
C
OMMANDS
4-231
Example
The following example shows how to map HTTP traffic to CoS value 0:
map ip precedence (Global Configuration)
This command enables IP precedence mapping (i.e., IP Type of Service).
Use the no form to disable IP precedence mapping.
Syntax
[no] map ip precedence
Default Setting
Disabled
Command Mode
Global Configuration
Command Usage
• The precedence for priority mapping is IP Port, IP Precedence or IP
DSCP, and default switchport priority.
• IP Precedence and IP DSCP cannot both be enabled. Enabling one of
these priority types will automatically disable the other type.
Example
The following example shows how to enable IP precedence mapping
globally:
Console(config)#interface ethernet 1/5
Console(config-if)#map ip port 80 cos 0
Console(config-if)#
Console(config)#map ip precedence
Console(config)#
