Options and Accessories

10-9

3-plate bi-fi required for operation > 20 ps. Standard 2-plate bi-fi is required for operation at < 20 ps.

Table 10-17: GTI and Bi-Fi for Broad Pulse Operation

GTI

Pulse Width (ps) Standard/Mid-range Long/X-Long

5 0445-9010-05 0445-9940-05

10 0445-9010-10 0445-9940-10

30 0445-9010-30 0445-9940-30

60 0445-9010-60 0445-9940-60

Bi-Fi

Blue/Standard/Long/X-Long Mid-range

5–10 0434-8953 0434-8954

30–60 0434-8973 0434-8974

Table 10-18: Photodiode PC Board

Assembly Part Number Wavelength (λ)

0452-3280 < 900 nm

0452-3250 > 900 nm
