Installation
5-5
8. Inspect for leaks at the hose connections just made, and also inside the
laser head where the polyurethane hoses attach to the front bezel and
to the rod holder.
9. Set the chiller temperature for 18°C (64°F).
This completes the installation of the chiller.
Removing the Chiller Hoses
from the Laser Head and Chiller
When you need to remove the hoses from the laser head, press on the side
button and pull the hose out. The quick-disconnect connectors are self-seal-
ing and no water will spill from the hoses.
Before removing the hoses from the chiller, refer to the chiller manual for
instructions on draining the unit or for capping the hose fittings.
Installing the Model 3910
Regulator/Filter Purge Unit
1. Verify the hoses inside the Model 3910 are still properly connected to
the plastic filters.
Turn the Model 3910 upside-down and visually inspect for loose con-
nections.
2. Place the Model 3910 in a convenient place within 3.5 m of the Tsu-
nami laser head.
3. Connect the purge line from the Model 3910 purge unit to the Tsunami
laser head.
Use the 3.5 m PTFE purge line provided to connect the Model 3910 to
the laser head. It comes with a Clip-Lok
®*
connector on one end and a
quick-disconnect connector on the other. The purge line is attached by
pressing the hose connectors onto their mating connectors until they
snap in place.
a. Attach the Clip-Lok
connector to the output of the Model 3910.
b. Attach the quick-disconnect connector to the purge input on the
Tsunami laser head input bezel.
*
Clip-Lok
®
is a registered trademark of Anarak, Inc.
Position the chiller so that its warm air exhaust does not adversely affect
the stability of the lasers on the table.
Caution!
PTFE tubing is included in the accessory kit for use when purging the
Tsunami laser with dry nitrogen. Using
PTFE tubing avoids introducing
outgassed impurities into the cavity that may degrade system perfor-
mance and/or cause damage to the optical coatings.
Warning!
