Installation
5-3
2. Align the Tsunami laser head input port to the pump beam.
a. Open the Tsunami interlock shutter by raising the red-capped lever
to the vertical override position.
b. Move the Tsunami until the pump beam passes through the center
of the input window and strikes the center of pump mirror P
1
(refer
to Figure 4-3).
The laser head should now appear to be aligned parallel to the
beam.
c Close the pump laser shutter.
d. Secure the Tsunami laser head to the table with the three foot
clamps provided.
The clamps slide over the lower portion of each foot.
e. Verify the height adjust locking nuts on the feet are tight.
This completes the installation of the Tsunami laser head.
Installing the Chiller
Detailed information on installing and starting the chiller can be found in
the manual supplied with the chiller.
1. Place the chiller on the floor close enough to the Tsunami laser head so
that the 3.5 m long hoses will reach from the chiller connectors on the
back of the unit to the Tsunami front bezel connectors and the Millen-
nia pump laser as shown in Figure 5-2.
Tsunami is a Class IV High Power Laser. Bypassing the safety interlock
shutter might expose the user to hazardous radiation. Always wear
proper eye protection and follow the safety precautions in Chapter 2,
“Laser Safety.”
Danger!
Laser Radiation
Be aware that during steps b and c invisible radiation could emit from
the output of the Tsunami laser and from various optical components as
well.
Danger!
Laser Radiation
Do not place the chiller above the lasers. Should the unit not be installed
properly and a leak develop, dripping water may damage one or both
lasers.
Warning!
