Tsunami Mode-Locked Ti:sapphire Laser
3-12
Specifications
Table 3-3 lists performance specifications for fs configurations pumped
with a Millennia-series laser. Table 3-4 lists performance specifications for
ps configurations pumped with a Millennia-series laser. Table 3-5 lists the
electrical, mechanical and physical specifications for the Tsunami laser.
Table 3-6 lists the environmental specifications. Specifications for the
optional Lok-to-Clock system are found in Table 3-7. Figure 3-5 through
Figure 3-10 earlier in this chapter show the tuning curves for typical fs and
ps systems, respectively.
Table 3-1: Tsunami Femtosecond Broadband Performance when Pumped by a Millennia laser
1
1
Specifications subject to change without notice and only apply when the Tsunami is pumped by a Spectra-Physics Mil-
lennia X or V diode-pumped CW laser.
720 nm 790 nm 850 nm 950 nm 1050 nm
2
2
Specifications apply to operation using the optional X-Long optics set.
Average Power
3
3
Specifications apply to operation at the wavelength noted
Millennia Xs 700 mW 1.4 W 1.2 W 400 mW 250 mW
Millennia VIIIs 500 mW 1.1 W 900 mW 250 mW N/A
Millennia Vs 300 mW 700 mW 500 mW 100 mW N/A
Peak Power
3
Millennia Xs > 65 kW > 170 kW > 145 kW > 48 kW > 24 kW
Millennia VIIIs > 47 kW > 134 kW > 109 kW > 30 kW N/A
Millennia Vs > 28 kW > 85 kW > 61 kW > 12 kW N/A
Pulse Width
3,4
4
A sech
2
pulse shape (0.65 deconvolution factor) is used to determine the pulse width as measured with a Spectra-
Physics Model 409 autocorrelator.
<130fs <100fs <100fs <100fs <130fs
Tuning Range
Millennia Xs 700–1000 nm 970–1080 nm
Millennia VIIIs 700–1000 nm N/A
Millennia Vs 710–980 nm N/A
Repetition Rate (nominal)
5
5
Laser operation is only specified at a nominal 80 MHz repetition rate.
80 MHz
Noise
6
6
Rms, measured in a 10 Hz to 2 MHz bandwidth.
<0.2%
Stability
7
7
Percent power drift in any 2-hour period with less than a ±1°C temperature change after a 1-hour warm-up.
<5%
Spatial Mode TEM
00
Beam Diameter at 1/e2 points <2mm
Beam Divergence, full angle <1mrad
Polarization > 500:1 vertical
