II. Electrical Measurement according to DIN EN 62353 (VDE 0751-1)
1.
Plug the bed mains cable in the
test socket on the measuring in-
strument
2.
Connect the measuring instrument
probe to the PE connector (mat-
tress base, head end).
3.
Activate the motors using the
handset for the duration of the
measurement.
III. Performance Check: OK Not ok Description of
Defect
What? How?
Performance Inspection of the Electrical Components (if installed)
Battery powered;
capacity of bat-
tery
Requirements: Battery is charged +
bed is disconnected from power sup-
ply: Test: Load bed with approx. 80
kg (=1 person); min. 2 cycles height
adjustment Up/Down until cut-out
must be possible.
End of travel cut-
out of the motors
Automatic cut-out in both end posi-
tions
Handset, foot
pedal; control
units, locking
functions
Test according to instruction manual.
No ‘rattling’ when shaken
Motors No abnormal noise level, no uneven
running
Backrest motor and manual CPR re-
lease
Control unit/
power pack and
motors
Test according to instruction manual
Strain Relief of
Mains Cable
Mains cable firmly fastened
Performance Inspection of the Mechanical Components (if Installed)
Appendix
Instruction Manual 152
