Li-Ion Battery, External (Optional)
Type Lithium ion technology: Nickel manganese cobalt oxide (NMC);
environmentally-friendly without heavy metals; integrated elec-
tronic charger unit with balancer and extended battery monitor-
ing;
Weight 0.7 kg
Capacity 2.25 Ah/ 58.28 Wh
Charging time Approx. 10 hours
Voltage DC 25.9 V
Protection category IP X6, suitable for automatic washing systems
Classification IEC 60601-1, 3rd Ed.; IEC 62133, 2nd Ed.; UL2054; UN38.3
Classification for transport UN3480: Shipping name: “LITHIUM ION BATTERIES”
Lifespan Up to 8 years under optimum conditions
Junction Box
Type MJBxx
Operating voltage DC 24 V
Protection category IP X6
Drive M1+M3: (electric) lift motors (depending on model)
Type LINAK LA 40
Path feedback 2 Hall sensors; analogue coding
Force/installation dimension/lift 8000 N/ 410 mm/ 215 mm
End position cut-out Micro-switch, with analogue coding
Input voltage DC 24 V
Duty cycle Intermittent duty: 2 min ON / 18 min OFF
Protection category IP X6
Product description
49 Instruction Manual
