Drive M2: (electric) thigh rest motor (depending on model)
Type LINAK LA27
Force/installation dimension/lift 4000 N / 272 mm / 70 mm
End position cut-out Micro-switch, with analogue coding
Input voltage DC 24 V
Duty cycle Intermittent duty: 2 min ON / 18 min OFF
Protection category IP X6
Drive M4: (electric) backrest motor (depending on model)
Type LINAK LA 40Q
Force/installation dimension/lift 4000 N / 433 mm / 205 mm
End position cut-out Micro-switch, with analogue coding
Input voltage DC 24 V
Duty cycle Intermittent duty: 2 min ON / 18 min OFF
Protection category IP X6
Product description
Instruction Manual 50
