5 Operation
Working with attachments
No.
Operating device
Function of the attachment
1
Joystick + shift
button "F"
Fork prong positioner: close/open
2
Vertical rocker
button + shift button
"F"
Fork positioner: forwards/backwards
3
Vertical rocker
button + shift button
"F"
Rotator: left/right
4
Vertical rocker
button + shift button
"F"
Clamp: close/open
5
Vertical rocker
button + shift button
"F"
Load retainer: close
/open
6
Vertical rocker
button + shift button
"F"
Additional fork carriage: lift/lower
Joystick + shift
button "F"
Fork prong positioner: close/open
7
Vertical rocker
button + shift button
"F"
Rotator: left/right
Joystick + shift
button "F"
Fork prong posi
tioner: close/open
8
Vertical rocker
button + shift button
"F"
Fork positioner: forwards/backwards
In the pictog
rams for possible attachments,
the outlined
graphic in the centre of the pic-
togram indic
ates the combination of operating
devices requ
ired for the particular attachment.
14
