5 Operation
Handling the battery
WARNING
Risk of crushing if the battery falls out.
Releasing the battery lock, as described below,
must only be carried out on horizontal, level ground
using a suitable battery change frame.
The battery lock lever may be actuated only when
the truck is stationary and the reach carriage is fully
retracted.
Prerequisites for replacing the battery
– For the correct use of the battery change
frame, refer to the information in the chapter
entitled "Battery change frame" and the
operating instructions, and comply with the
manufacturer’s safety regulations.
Maintenance personnel for batteries
Batteries may only be charged, maintained
or changed by properly trained personnel
in accordance with the instructions of the
manufacturers of the battery, battery charger
and truck.
– The handling instructions for the battery and
the operating instructions for the battery
charger must be followed.
Positioning the truck correctly in relation
to the battery rack
CAUTION
Before replacing the battery, ensure that the rollers
for the battery transport in the battery rack are
alignedwiththerollersinthetruck. Failuretodo
so could cause damage to the battery rack rollers
and locking mechanism.
The truck must be placed in such a position
relative to the battery rack that the transition of
the battery between the truck and the battery
rack can be performed without mechanical
resistance.
– Make sure that the transfer height of the
battery rack is correctly adjusted to that of
the truck, refer to the chapter entitled "Bat-
tery change frame/Adjusting the transfer
height".
20
6 50988078001 [EN]
