Note – FB-DIMM names in ILOM messages are displayed with the full FRU name,
such as /SYS/MB/CMP0/BR0/CH0/D0.
4.6 Replacing FB-DIMMs
This section describes how to diagnose and replace faulty FB-DIMMs. For FB-DIMM
configuration guidelines, see Section 4.5, “FB-DIMM Layout” on page 4-19.
Caution – Ensure that all power is removed from the server before removing or
installing FB-DIMMs. You must disconnect the power cables before performing this
procedure.
Branch 1 Channel 0 /SYS/MB/CMP0/BR1/CH0/D0 J1401 1 C
/SYS/MB/CMP0/BR1/CH0/D1 J1501 3 D
Channel 1 /SYS/MB/CMP0/BR1/CH1/D0 J1601 2 C
/SYS/MB/CMP0/BR1/CH1/D1 J1701 3 D
Branch 2 Channel 0 /SYS/MB/CMP0/BR2/CH0/D0 J2001 1 E
/SYS/MB/CMP0/BR2/CH0/D1 J2101 3 F
Channel 1 /SYS/MB/CMP0/BR2/CH1/D0 J2201 2 E
/SYS/MB/CMP0/BR2/CH1/D1 J2301 3 F
Branch 3 Channel 0 /SYS/MB/CMP0/BR3/CH0/D0 J2401 1 G
/SYS/MB/CMP0/BR3/CH0/D1 J2501 3 H
Channel 1 /SYS/MB/CMP0/BR3/CH1/D0 J2601 2 G
/SYS/MB/CMP0/BR3/CH1/D1 J2701 3 H
* Upgrade path: DIMMs should be added with each group populated in the order shown.
† Fault replacement path: Each pair is addressed as a unit, and each pair must be identical.
TABLE 4-1
FB-DIMM Configuration
Branch Name Channel Name FRU Name
Motherboard FB-DIMM
Connector
FB-DIMM
Installation
Order
*
FB-DIMM
Pair
†
