4-36 Sun Netra T5220 Server Service Manual • January 2012
3. Install the air duct.
See Section 4.4.2, “Installing the Air Duct” on page 4-18.
4. Install the PCI mezzanine.
See Section 6.1.1, “Installing the PCI Mezzanine” on page 6-1.
5. Bring the server back online.
See Section 4.1, “Powering Off and Powering On the Server” on page 4-1.
6. If the previous SCC module had modified ILOM configuration variables and
you recorded them, configure the new SCC module with those values.
7. Return the server to operation.
See Chapter 6.
4.10 Replacing the Motherboard Assembly
Caution – The SCC module contains system host ID, MAC addresses, and
configuration variable settings for ILOM. If you are replacing a motherboard, you
must move the SCC module from the old motherboard to the new one. You must also
backup OpenBoot PROM variables for restoring after motherboard replacement.
4.10.1 Removing the Motherboard Assembly
1. Back up OpenBoot PROM variables with one of the following procedures:
■ For ILOM 3.0 Web Interface – Back up per the Oracle Integrated Lights Out
Manager (ILOM) 3.0 Web Interface Procedure Guide (820-0052). Use a passphrase to
backup the OpenBoot PROM variables.
■ For ILOM 3.0 CLI – Back up per the Oracle Integrated Lights Out Manager (ILOM)
3.0 CLI Procedure Guide (821-1611). Use a passphrase to backup the OpenBoot
PROM variables.
■ For ILOM 2.0 – The ILOM Back up/Restore feature is absent. Record output from
the OpenBoot PROM printenv command or the Oracle Solaris eeprom command
for use after motherboard replacement.
2. Prepare the server for motherboard assembly removal. See Section 4.1,
“Powering Off and Powering On the Server” on page 4-1.
