4-2 Sun Netra T5220 Server Service Manual • January 2012
■ Section 2.3.4, “Performing Antistatic Measures” on page 2-8
To bring the server back online, perform the following procedures:
■ Section 6.1.2, “Installing the Top Cover” on page 6-3
■ Section 6.1.3, “Removing Antistatic Measures” on page 6-4
■ Section 6.1.4, “Reinstalling the Server Chassis in the Rack” on page 6-5
■ Section 6.1.5, “Reconnecting Cables to the Server” on page 6-7
■ Section 6.1.6, “Powering On the Server” on page 6-8
4.2 Replacing PCI-X, PCIe/XAUI Cards
4.2.1 PCI Card Retainers
The PCI mezzanine secures the PCIe cards into place with green PCI card retainers
and captive (nonremovable) screws. The following figure shows the four PCI card
retainers that ship with the server.
