Chapter 4 Replacing Motherboard Assembly Components 4-15
4.3 Cabling the Sun Storage 6 Gb SAS PCIe
RAID HBA, Internal
Refer to the Sun Storage 6 Gb SAS PCIe RAID HBA, Internal Installation Guide (E22410)
for additional details.
This HBA requires a separate SAS cable (530-4088-01) that ships with the card, or can
be ordered separately.
▼ Cable the Sun Storage 6 Gb SAS PCIe RAID
HBA, Internal
1. Remove the existing SAS cable connected to the SAS BackPlane (BP) connector
and the motherboard near slot 0.
2. Install the card in PCIe slot 0, see Section 4.2.5, “Installing the Lower PCIe/XAUI
Cards” on page 4-12.
3. Connect the SAS cable (530-4088-01) to port SAS0 on the card and the SAS BP
connector.
Route the SAS cable as shown in the following figure.
